SKU - HDR.2700.500.3

Features:

  • These lightweight Aluminium ramps are ideal for loading excavators, skid steer loaders, ditch witches, mini excavators and many more.
  • These ramps are suited to rubber tracked machines
  • The connecting plate and pin ensure maximum stability and safety

Specifications:

Length (mm): 2700
Inner Width (mm) :405
Outer Width (mm) :500
Height of Ramp Profile (mm):112

Space Between Rungs: 90mm
Rung Type: Angle
Max Load Height (mm): 810
Weight per Ramp (Kg): 30
Load Capacity per pair (Kg): 3000

(HDR.2700.500.3)

SKU HDR.2700.500.3
Brand Ramptec
Shipping Weight 60.0000kg
Shipping Width 0.500m
Shipping Height 0.230m
Shipping Length 2.700m
Shipping Cubic 0.310500000m3
